Specification

Minimum working weight4180 kg9220 lb
Weight3860 kg8510 lb
Height2700 mm106.3 in
Max. jaw opening1150 mm45.28 in
Jaw width660 mm26.0 in
Max. cutting force3840 kN
Max. crushing force1980 kN
Operating pressure280 - 320 bar4060 - 4640 psi
Max. operating pressure320 bar4640 psi
Oil flow range280 - 320 l/min74.0 - 84.5 gal/min
Closing time at max oil flow3.5 s
Opening time at max oil flow3.4 s
No. of cycles per minute at max oil flow8.7
Cutting blade length220 mm8.66 in
Max. diameter to be cut65 mm2.56 in
Pressure line connection (IN)SAE 6000 psi 1 1/4"
Return line connection (OUT)SAE 6000 psi 1 1/4"
Optimum oil temperature40 - 60 °C104 - 140 °F
Allowed oil temperature range-20 - 80 °C-4 - 176 °F
Optimum oil viscosity at operating temperature30 - 60 cSt
Allowed viscosity range20 - 1000 cSt
Carrier weight, range  *135 - 45 t77200 - 99200 lb
*1   Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.

Specifications are subject to change without notice (Tuesday, June 21, 2022)
