Minimum working weight, flange mounted  *1285 kg630 lb
Weight232 kg510 lb
Impact rate (frequency)550 - 1050 bpm
Operating pressure70 - 130 bar1015 - 1885 psi
Oil flow range30 - 60 l/min7.9 - 15.9 gal/min
Pressure relief setting  *2150 bar2175 psi
Pressure relief max170 bar2465 psi
Back pressure max20 bar290 psi
Input power13 kW17 hp
Tool diameter60 mm2.36 in
Pressure line connection (IN)BSPP internal 3/4"
Return line connection (OUT)BSPP internal 3/4"
Pressure line size, min. inner diameter15 mm0.59 in
Return line size, min. inner diameter15 mm0.59 in
Optimum oil temperature40 - 60 °C104 - 140 °F
Allowed oil temperature range-20 - 80 °C-4 - 176 °F
Optimum oil viscosity at operating temperature30 - 60 cSt
Allowed viscosity range20 - 1000 cSt
Skid steer, robot weight, range  *32.0 - 3.7 t4400 - 8157 lb
Carrier weight, range  *33.0 - 6.0 t6600 - 13228 lb
Noise level, guaranteed sound power level, LWA  *4114 dB
Noise level, measured sound power level, LWA  *4118 dB
*1   Includes average mounting bracket and standard wear parts
*2   Minimum setting = actually measured operating pressure + 50 bar or 725 psi
*3   Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.
*4   According to European Union DIRECTIVE 2000/14/EC

Specifications are subject to change without notice (Wednesday, August 23, 2023)


The Standard Chisel Tool is used for rock and reinforced concrete.
Moil Point tools allow for optimum positioning in material which is loose or can be easily separated, e.g. brick walls or loose rock in tunn...
The pyramid tool is a further development of the moil point tool and is intended for penetrative work. Its pyramid shape allows optimal posi...


RD3 is the latest in monitoring technology for hydraulic hammers. The monitoring data is available for all stakeholders through the SAM digi...
Tool grease is essential when using hydraulic hammers. It needs to withstand high temperatures and pressure. Our special tool grease has bee...
BIO Tool grease is a modern high performance biodegradable grease for hydraulic hammers. This tool grease is specially formulated to be envi...
